Product Overview
U disk player can play MP4 files in U disk, MP4 files need to use our transcoding tool transcoding. Video is output in three forms: 1. Output to the monitor via HDMI; 2. is transferred to the network video; 3. Output in the form of emulated USB camera through USB OUT interface. The backend can be used to randomize the playback of files or to play the previous and next files.
Output a variety of cooperative PTE private protocol to achieve LAN low delay transmission only 80-200 milliseconds, RTMP/ RTSP /HTTP TS/HTTP FLV/HLS /SRT/UDP multicast /RTP multicast and other protocols. You can fill in up to 6 different RTMP push stream location push stream local server or live broadcast platform for live broadcast. Multicast supports multiple LAN clients to watch at the same time. It supports ONVIF protocol to connect with NVR, and NVR can record and play.
Is widely used in advertising, education, medical treatment, conferences, video surveillance, all kinds of live broadcast and other fields.
Functional Features
1.Convert U disk video to 1 channel network video
2.Can be pushed to 6 live platforms at the same time
3.Support live broadcast such as Douyin Kuaishou
4.Usb video can be played through HDMI output
5.USB disk video can be output and played in the form of USB camera through USB OUT interface
6.Maximum resolution frame rate: 1920*1080P60
7.Low-latency private protocol: PTE (80-200 ms) 8.Video protocol: RTMP/RTSP/HTTP TS/HTTP FLV/SRT/HLS/UDP multicast /RTP
9.Support GB28181 protocol docking
10.Support ONVIF search and browse video docking NVR
11.Audio: U disk audio input,HDMI built-in audio output, 3.5mm audio input, support stereo
12.Configure parameters and upgrade firmware through the WEB
