Description
FEATURES
* 1*HDMI+3.5mm audio input with HDMI loop out
* Supporting up to 4 TS over IP stream out, 4 streaming out version price different
* Encoding level: Level 1/2/3/4/5(the higher level, the higher stream fluctuation rate)
* Switchable audio output mode: Left, right and Stereo
* Display on multi-screens from a computer is available
* Workable under HLS, RTSP/HTTP/UDP, RTMP unicast and multicast(Username and password verification allowed
under RTMP)
* Support ONVIF network video protocol
* Multi-protocol, multi-resolution and multi-bitrate are configurable
* Any iOS device browser (iPhone, iPad, MacBook etc) is able to have streams from IPTV Streaming Encoder Anytime,
Anywhere by HLS protocol without installing any software players
* Any terminal device/decoder is able to have streams from IPTV Streaming Encoder directly by RTMP protocol with
software players(such as VLC)
* Audio encoded bit-rate: 48kbps/64kbps /96kbps/128kbps/160kbps/192kbps /256kbps
* Bit-rate mode CBR/VBR,16Kbps~12Mbps
* Video packing: FFMPEG/VLC
* Transport method: TCP,UDP,1000M (RJ45 duplex interface)
* Web-based management easy for configuration.
* Scrollable English OSD ,picture overlay and logos are supported so that letters and symbols can be displayed anywhere
in the screen
* Allowing DHCP to automatically obtain IP, offering one key recovery & upgrading and remote maintenance.
* Image setup: contrast, brightness, hue, saturation, noise inspection, sharpness, wave filtering
* Audio: embedded or line in; left & right; built-in audio gain for independent volume adjustability
* Able to encode with absence of video signal
* The setting comes into effect once finished while reboot is unnecessary
* Default configuration can be done by one key recovery
* WINDOWS XP/VISTA/SERVER 2003/SERVER 2008/WIN7 32 and WIN7 64, LINUX are supported
Highlight
Webrtc for ultra low latency over WAN in 3 terminals, play by browser in 3 terminals over WAN by HTTPS URL
Low latency transmission for live streaming application
