Specification |
Parameter |
||||
|
Audio and video in |
Video in |
RTSP/HTTP TS/HTTP FLV/HLS/RTMP/RTMPS /UDP/RTP/SRT/PTE |
|||
|
Input coding type |
H.264/H.265/VP9/AV1/AVS2 |
||||
|
Audio in |
Original/Analog/Mixed |
||||
|
Tanscode |
Video transcode |
Channel |
Tanscade |
Decode |
Maximum processing capacity |
|
1 |
Supports |
Supports |
4060*2160@60 |
||
|
2 |
Supports |
Supports |
4060*2160@30 |
||
|
3 |
Supports |
Supports |
1920*1200@60 |
||
|
4 |
Supports |
Supports |
1920*1200@60 |
||
|
5 |
Disable |
Supports |
1920*1200@25 |
||
|
6 |
Disable |
Supports |
1920*1200@25 |
||
|
9 |
Disable |
Supports |
1920*1200@25 |
||
|
16 |
Disable |
Supports |
1280*720@25 |
||
|
25 |
Disable |
Supports |
640*480@15 |
||
|
36 |
Disable |
Supports |
640*480@15 |
||
|
Audio action |
Select any channel |
||||
|
Encoding Type: |
H.264/H.265 |
||||
|
FPS |
5-60 |
||||
|
GOP |
5-300 |
||||
|
Bitrate(kbit) |
32-32000 |
||||
|
Encoded Size |
1920x1200/1920x1080/1680x1056/1680x1050/1600x1200/1600x900/1366x768/1280x1024/1280x720/1024x768/1024x576/960x540/850x480/800x600/720x576/720x540/720x480/720x404/704x576/640x480/ 640x360/640x350/608x448/544x480/512x288/480x480/480x384/480x360/480x320/480x272/480x270/400x320/400x224/352x480/352x228/320x256/320x240/320x180/240x180 |
||||
|
H.264 Level |
baseline profile/main profile/high profile |
||||
|
Bitrate Control |
CBR/VBR/Strong cbr |
||||
|
Stream |
RTMP/ RTSP /HTTP TS/HTTP FLV/HLS TS/HLS MP4/MP4/SRT/UDP /RTP/SRT |
||||
|
Audio transcode |
Encoder |
AAC /AAC+/AAC++/MP3/MP2/ AC3/Opus |
|||
|
Bitrate |
AAC:48000~320000/AAC+:24000~48000/ AAC++:12000~32000/MP3:64000~320000 / MP2: 64000~320000/ AC3:40000~640000/Opus:8000~256000 |
||||
|
G711A Over PTE |
Disable/Enable |
||||
|
G711 |
Disable/Enable |
||||
|
G711 Over RTSP |
Disable/Enable/Enable and resample with 8K |
||||
|
OSD |
TYpe |
Text/Img/Scrolling text /Time |
|||
|
Transparency |
0-255 |
||||
|
Zone |
4 Zone |
||||
|
X |
0-1920 |
||||
|
Y |
0-1080 |
||||
|
LOGO |
4 logos can be uploaded for selection |
||||
|
Font size |
8-72 |
||||
|
Background color |
Transparent/White/Black |
||||
|
Font color |
RGB Color |
||||
|
Output |
HD output |
Auto adapt/720x576p50/1280x720p50/1280x720p60/1366x768p60/ 1920x1080p24/1920x1080p25/1920x1080p30/1920x1080i50/1920x1080p50/1920x1080i60/1920x1080p60/1600x1200p60/1920x1200p60/ 2560x1440p60/3840x2160p24/3840x2160p25/3840x2160p30/3840x2160p50/3840x2160p60 |
|||
|
Screen rotation |
Disable /90°/180°/270° |
||||
|
Output Layout |
Custom layout |
||||
|
Source name display |
Disable/Enable |
||||
|
Video borde |
Disable/Enable |
||||
|
Lost signal prompt |
Disable/Enable |
||||
|
Clear screen on signal loss |
Disable/Enable |
||||
|
Brightness |
0-100 |
||||
|
Contrast |
0-100 |
||||
|
Hue |
0-100 |
||||
|
Saturation |
0-100 |
||||
|
Audio |
Disable/Enable |
||||
|
Volume |
0-100 |
||||
|
Audio level |
Disable /Left /Right /Top /Bottom /Left +Right /Top+Bottom |
||||
|
Tansmit
|
Video tansmit |
Channel |
4 |
||
|
Stream |
RTMP/ RTSP /HTTP TS/HTTP FLV/HLS/MP4/SRT/UDP/RTP |
||||
|
Audio tansmit |
Encoder |
AAC /AAC+/AAC++/MP3/MP2/ AC3/Opus |
|||
|
Bitrate |
AAC:48000~320000/AAC+:24000~48000/ AAC++:12000~32000/MP3:64000~320000/ MP2: 64000~320000/ AC3:40000~640000/Opus:8000~256000 |
||||
|
G711A Over PTE |
Disable/Enable |
||||
|
G711 |
Disable/Enable |
||||
|
G711 Over RTSP |
Disable/Enable/Enable and resample with 8K |
||||
|
Common |
Network |
Duble 1000Mbps |
|||
|
Configuration |
WEB,Upload,Reset |
||||
|
ONVIF |
Support ONVIF to search and browse videos |
||||
|
Power Supply |
12V/DC,2A |
||||
|
Power |
<5W |
||||
|
Temperature |
-20℃+60℃ |
||||
|
Humidity |
<90%, non-condened |
||||
|
Size |
365g |
||||
|
Weight |
17*10.3*3.4cm |
||||
