| Item | Description |
| Network Protocol | |
| Protocol | Support SRT/HLS/RTSP/HTTP TS/HTTP FLV/RTMP/UDP |
| Video Decoding Capacity | |
| Decoding format | H.264/H.265 Baseline/Main/High Profile Level4.2 |
| Frame Rate | 1-60fps |
| Bit rate(kbit) | 32kbps-32Mbps |
| Resolution | Up to 4K@30 |
| Channel number | Up to 4 Channels |
| Audio Decoding Capacity | |
| Decoding format | G711A/G711U/AAC+/AAC++/MP2/MP3 |
| Audio mode | Mono/Left, Right/Stereo |
| Sample rate(Hz) | 8KHz/11.25KHz /22.5KHz /44.1KHz /48KHz |
| Channel number | 1 Channel |
| Video Output | |
| HDMI | 4K@30fps,1080P@60/50fps,1080I@60/50fps,1080P@30/25fps, 720P@60/50fps,576P@50fps,480P@60fps |
| VGA | The same as HDMI |
| SDI | 1080P@60 fps, 720P |
| Color | Brightness, Contrast, Hue, Saturation can be adjustable |
| Audio Output | |
| HDMI audio embedded | 48KHz stereo output |
| 3.5mm | Stereo output (Left & Right) |
| Audio control | Enable/Disable |
| The Working Environment | |
| Warranty | 3 years with free telephone support |
| Network | 1000M |
| Management | Web management |
| Power | 12V/DC, 2A |
