| I/O Per Modular | |
| Connector Type | Two 10/100M Ports for IP streaming and Control GUI |
| IP Protocol | 1xMPEG-TS( SPTS) Over IP input per modular |
| TS Over RTSP/HTTP | |
| UDP/IP (Unicast and Multicast) | |
| RTMPS/RTMP(Flash) | |
| HTTP Live streaming Apple HLS (m3u8) | |
| Two different IP protocol out per Transcoding Channel | |
| Max. Numbers | 1x HD (Compact) |
| 4x HD (1RU) | |
| 16x HD (3RU) | |
| Pre-processing | |
| Frame rate | 5fps to 60fps, by default configure to 30fps |
| Image insertion | Logo(bmp file), OSD insertion |
| Enhancement filter | Deinterlacing; Noise reduction; Sharpening; Visual Optimizing; Filtering |
| MTU | 1~1500 |
| TTL | 1~255 |
| Key Interval | 5~200 |
| Encoding Schemes | VBR,CBR |
| MUX mode | video&audio or audio only |
| HD to SD down conversion | |
| Frame rate reduction | |
| Video Transcoding | |
| Input: | MPEG-4 AVC HP @L4.0, HP @L4.2 (HD) MPEG-4 AVC MP @L3.0 (SD) MPEG-2 HP @HL (HD) MPEG-2 MP @ML (SD) MPEG-4 AVC HP @L4.0, HP @L4.2 (HD) MPEG-4 AVC MP @L3.0 (SD) MPEG-H HEVC (ISO/IEC 23008-2) |
| Output: | MPEG-4 AVC HP @L4.0, HP @L4.2 (HD) MPEG-4 AVC MP @L3.0 (SD) MPEG-4(HIGH/MAIN /Baseline) MPEG-H HEVC (ISO/IEC 23008-2) |
| Video resolution | |
| Input: | 1920×1080 @60P, 1920×1080 @60i, 1920×1080 @50P, 1920×1080 @50i, 1920×1080 @30P,1280×720 @60P, 1280×720@50P 720×576 @50i,720×480 @60i 640×480/360, 480×270, 320×240, 320×180 |
| Output: | 19201080 @30P, 1920×1080 @30P, 1920×1080 @25P, 1920×1080 @25P 1280x720 @60P, 1280x720 @50P 720×576 @25P,720×480 @30P Auto |
| Bitrate of Res. | 720x576 (D1) 800-1500kbps 1080x720p (HD) 1500-3000kbps 1920x1080p (Full HD) 3500-6000kbps Video Bitrate 16kbps to 12Mbps |
| Audio Transcoding | |
| MPEG-1 Layer II stereo | |
| MPEG-4 AAC-LC stereo | |
| MP3 | |
| G711 (Only RTSP ip protocol support) | |
| Environment | |
| Power Supply | +12V (Compact size), 110/220V (1RU/3RU) |
| Power consumption | <5W (compact) <15W(1RU) <80W (1/3RU) |
| Operation temperature | 0 -50°C (32 -122°F) |
| Storage temperature | -40-70°C (-40-158°F) |
| Dimensions | 180 x110x 50 mm (Compact) 430 x 250x 45mm (1RU) 560 x 450x 270 mm (3RU) |
| Weight | 1.0kg (Compact); 4.0kg (1RU); 7.5kg (3RU) |
| Ordering Information | |
| 1 Modular | |
| 4 Modular | |
| 16 Modular | |
