4K 3-Sim cellular bonding encoder is an advanced bonding encoder that fully developed by KUNUOMAGIC technology, it allows to transmit max 3840* 2160 30 FPS video over 3 aggregated Sim cards, support simultaneously output to three different platform over RTMP (Main stream: 2 *4K, 2nd stream: 1* 1080), supports HTTP- RTSP over UDP/ TCP- RTMP- UDP Unicast/ multicast/ - ONVIF- HLS- P-P protocol.
Specifications
|
Model |
4G 4K bonding |
|
|
Input |
1* HDMI, 1* 3.5MM audio Jack |
|
|
Output |
H.264/ H.265 TS stream |
|
|
Video |
Input Resolution |
3840*2160 and below |
|
Encoding |
H.265 main profile H.264 BASELINE PROFILE/ H.264 MAIN PROFILE/ H.264 HIGH PROFILE |
|
|
Encoded size |
Up to 3840* 2160 |
|
|
Bitrate |
200 kb/s~512000kb/s |
|
|
Frame |
3840-2160-30 fps, 1920*1080-60 FPS |
|
|
OSD |
Text, image |
|
|
Audio |
Input |
1* HDMI embedded audio, 1* 3.5 mm Audio Jack (active audio) |
|
Output |
1* 3.5 audio Jack |
|
|
Encoding |
AAC/ MP3/ G.711 |
|
|
Bitrate |
64Kb/s~384Kb/s |
|
|
Sampling |
32000, 44100, 48000 etc |
|
|
Internet |
RJ45 1000M/100M adaptive network, 4G (3* Sim), WIFI |
|
|
System |
Network protocol |
HTTP, RTSP, RTMP, UDP, Unicast, multicast, HLS, RTP, P-P, ONVIF |
|
Configuration |
Linux/ Windows/ Mac based IE browser, APP |
|
|
RS485 |
PELCO-D, PELCO-P |
|
|
Storage |
TF card (max 128G, providing (paid): CLASS10 64G TF card) |
|
|
Power |
12V~2A |
|
|
Consumption |
8W |
|
|
Size |
102mm x 132mm x 28mm |
|
|
Battery |
7.4V 4500MAH Li-polymer |
|
|
temperature |
-20℃+ 60℃ |
|
|
Humidity |
<90%, non-condensation |
|
|
Weight |
0.4KG |
|
|
|
||
