HD SDI 4G Video Encoder Wifi Live streaming IPTV encoder
No.YNS-2320G
YNS-2320G 4G/3G HD ProVideo Streaming Encoder features high performance, low latency and low bit rates for Live Streaming, IPTV & OTT systems, realized Video & Audio real-time transmission via 4G/3G internet, and adopts state-of-the-art compression techno
Overview YNS-2320G 4G/3G HD ProVideo Streaming Encoder features high performance, low latency and low bit rates for Live Streaming, IPTV & OTT systems, realized Video & Audio real-time transmission via 4G/3G internet, and adopts state-of-the-art compression technology of H.265/HEVC, which realizes its resolution to be up to full HD 1080P. With powerful video pre-compression and efficient adaptive video compression algorithm, it is able to provide clear-delicate, high quality video even at lower bit rate which can efficiently save the cost of bandwidth. YNS-2320G accepts 1*SDI Interface then outputs 4*streams H.265 format and audio MP3/AAC format with multi-protocol, multi-resolution, multi-bitrate which can be freely adjusted according to your needs. Besides, it’s simple to be set up by switching between WIFI and 4G LTE mode, users can start Live Streaming Anytime, Anywhere, Anyplace! YNS-2320G provides fully functional second development package, which can be applied to education, health care, IPTV, conference, remote education, news interview, court, public security, banking, transportation and other industry application. Main Feature
3G/4G LTE/WIFI/LAN(Switchable)
low power consumption design & running time up to 5-6 hours by full built-in Lithium battery.
Support up to 4 TS over IP stream out.
Providing a standard hot shoe base for fixation on a camcorder
Workable with newest architecture of H.265
Display on multi-screen originated from one computer is available
Up to Full HD 1080P output.
Workable under HLS,RTSP/RTP/RTMP, HTTP, UDP unicast and multicast(Username and password verification allowed under RTMP)
Support HDCP protocol
Support ONVIF Network Video Protocol
Configurable of multi-screen ,multi-protocol, multi-resolution and multi-stream and low bit-rate by H.265 with high quality image
Any iOS browsers(iphone, ipad, MacBook etc) are able to have streams from IPTV Streaming Encoder in Anytime, Anywhere by HLS protocol without install any software players.
Any terminal devices/decoders are able to have streams from IPTV Streaming Encoder directly by RTMP protocol with software players(such as VLC).
Audio: embedded or line in; left & right; built-in audio gain for independent volume adjustability
Able to encode with absence of video signal
The setting comes into effect once finished while reboot is unnecessary
Default configuration can be done by one key recovery
WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN7 64, LINUX
High Lights Support 3G/4G Wifi + Lithium bttery at the same time. Battery
Compatible with Wowza/FMS/RED5 streaming media server etc, work in with streaming media server to push the streaming , to achieve a live streaming
low Latency: less than 200ms when decoding by our Decoder
Specifications VIDEO Encoding Video compression: H.265 HEVC,H.264/MPEG4 Video inputs:1*SDI in Input resolution: 1920x1080,1680x1056,1280x720,1024x576,850x480,720x576,720x540, 720x540,720x480, 720x404,704x576,640x480,640x360,auto Output resolution: Main stream(supports two protocols): 1920x1080,1680x1056,1280x720,1024x576,850x480,720x576,720x540, 720x540,720x480, 720x404,704x576,640x480,640x360,auto Sub-stream(supports two protocols): 1280x720,800X450,720x576,720x540,720x480,720x404,704x576,640x480, 640x300,352X288,320X240,320X180 auto Bit-rate: 16kbps~12Mbps, CBR/VBR OSD: text, photo Video pre-processing: Noise reduction, Sharpen, Filtering AUDIO Encoding Input interface: 1*SDI Interface Audio compression: AAC, MP3 Sampling Rate: 32KHz,44.1 KHz,48 KHz etc. Audio Bit-rate: 48Kbps,64 Kbps,96 Kbps,128 Kbps,16 Kbps,192 Kbps,256 Kbps,384Kbps IP Streaming output Transport protocol: TS over IP output, HLS, RTSP, HTTP, RTMP, UDP multicast/unicast, ONVIF protocol Support RTMP Username and Password for verification of IPTV Server Connector: RJ45,100M/1000M
GENERAL OPTIONS System Configuration Interface: Web-based Remote Upgrade: via network Connector: RJ45, 100M/1000M Ethernet interface. Physical and Power Voltage: 5V Power: 2.4A Power Consumption: 10W Operating temperature: -20~60℃(operation), -20~65℃(storage) Working Moisture: <90% no condensation Dimensions: 102mm(L)*72mm(W)*25mm(H) Net Weight: 0.4 KG LTE mode: 3G/4G LTE Lithium Battery: 10000MAH Application:
IPTV & OTT system
Internet TV
Digital Signage Project
Remote Video Conference
Video Monitoring
Live Streaming
Digital TV Broadcasting System
Digital TV Programs Transmission
Hotel TV System
Head-end system of Digital TV branch network
CATV Broadcasting system
Edge side of Digital TV backbone network
