| Model | YDS3000DPLUS |
| Output | |
| Video | SDI*2 |
| Output Resolution | 1080P@60, 1080P59.94, 1080P@50, 1080P@30, 1080P29.97, 1080P@25, 1080P24, 720P@60, 720P@50, 720P@59.94 1080I@60, 1080I59.94, 1080I@50, 576P50, 576I50, 480I60 |
| Decoding | H.265/H.264 |
| Output | 1 /4 channels 1080P decoding, 9 channels 720P decoding |
| Audio | |
| Decoding format | AAC MP3 |
| Stereo | Adjustable sound volume |
| System | |
| LCD | Device name, IP address, resolution and working status |
| RJ45 | 1000M internet access |
| Protocol | HTTP, HTTPS,RTSP, RTMP, SRT, UDP/RTP,SRT… |
| Interface | WEB operation interface |
| Upgrade | Software upgrading through the internet |
| General Parameters | |
| Dimension | 6.4*4.4*1.3in(163*111*32mm) |
| Weight | 0.35kg |
