DVB-S S2 S2X Professional Satellite Receiver IP Gateway

Input / Output

4 Tuner input, F Type
5 MPTS (4 MPTS out thru bypassing, 1 MPTS multiplexing) out over UDP/RTP thru Data port, 100/1000Mself-adaption, unicast/multicast

Mux

Max number of managing PID: 256 (for 1 MPTS out thru multiplexing)

Functions

PID remapping (automatically/ manually)

PID pass-through

Tuner Section

DVB-S

Input Frequency

950-2150MHz

Symbol Rate

0.5~45 Msps

Constellation

QPSK

FEC

1/2, 2/3, 3/4, 5/6, 7/8

DVB-S2

Input Frequency

950-2150MHz

Symbol Rate

QPSK/8PSK/16APSK: 0.5~45 Msps
32APSK:0.5~40 Msps

Constellation

QPSK/8PSK/16APSK/32APSK

FEC

QPSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9,9/10
8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
16APSK: 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
32APSK: 3/4, 4/5, 5/6, 8/9

Max input bitrate per tuner

≤170 Mbps

DVB-S2X

Symbol Rate

QPSK/8PSK/16APSK: 0.5~45 Msps;
8APSK/32APSK: 0.5~40 Msps

Constellation

QPSK/8PSK/16APSK/8APSK/32APSK

FEC

QPSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10, 13/45, 9/20, 11/20
8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10, 23/36, 25/36, 13/18
8APSK: 5/9-L, 26/45-L
16APSK: 2/3, 3/4, 4/5, 5/6, 8/9, 9/10,1/2-L, 8/15-L, 5/9-L, 26/45, 3/5, 3/5-L, 28/45, 23/36, 2/3-L, 25/36, 13/18, 7/9, 77/90
32APSK: 3/4, 4/5, 5/6, 8/9, 2/3-L, 32/45, 11/15, 7/9

Max input bitrate per tuner

≤170 Mbps

Signal Strength

-65 ~ -25dBm

System

Web management:100M NMS port

Language: English and Chinese

Ethernet software upgrade

General

Dimensions

482mm×328mm×44mm (WxLxH)

Weight

3.5kg

Temperature

0~45℃(operation), -20~80℃(storage)

Power supply

AC 110V±10%, 50/60Hz Or AC 220V±10%, 50/60Hz

Consumption

≤40W
