YDS3304T is a 1RU rack-mountable compact headend with 4 100Mbps RJ45 ports for signal
input. It is designed to meet the growing demand for content distribution over IP network. YDS3304T
supports multiplexing and modulating with dense IP input and up to 4 adjacent carriers’ output. It is a
great value for program redistribution which can meet different system integration needs. It is perfect for
hotels, hospitals, schools, jails, entertainment venues, etc..
4 100Mbps RJ45 input ports
Output 4 non-adjacent channels within frequency range: 50-999MHz
Support unicast and multicast over UDP/RTP, IGMP V2/V3
63 IP (SPTS) input over UDP/RTP protocol
Excellent RF output performance index, MER≥40db
Support PID filtering, re-mapping and PSI/SI update synchronously
Fully complying with DVB-C(J.83A/B/C), DVB-T, DTMB, ATSC standard
Web-based NMS operation
