| Specification | Parameters | ||
| Video Audio Input |
Video input |
IP Streamings |
|
| Audio input |
Network stream built-in audio and 2-channel external audio to choose one of three |
||
| Transcoder | Video Transcoder |
Channels | 1/2/4/9 |
| Audio Play | choose any one channel |
||
| Encoding | H.264/H.265 | ||
| Frame Rate | 5-60 adjustable |
||
| Keyframe interval (frames) |
5-300 adjustable |
||
| Bit rate (kbit) |
32-32000 Adjustable | ||
| Encoded Resolution |
1920x1200/1920x1080/1680x1056/1680x1056/1600x1200/1600x900/1366x768/1280x1024/1280x720/1024x768/1024x576/960x540/850x480/800x600/720x576/720x540/720x480/720x404/704x576/640x480 | ||
| H.264 Profile |
baseline profile/main profile/high profile | ||
| Stream Control |
CBR/VBR Optional | ||
| Transcoded streaming protocol |
Support RTMP/ RTSP /HTTP TS/HTTP FLV/HLS/MP4/SRT/UDP Multicast/RTP Multicast |
||
| Audio Transcoding |
Encoding | AAC /AAC+/AAC++/MP3/MP2/ AC3/Opus |
|
| Encoding bit rate |
AAC:48000~320000 adjustable/AAC+:24000~48000 adjustable/ AAC++:12000~32000 adjustable /MP3:64000~320000 adjustable / MP2: 64000~320000 adjustable / AC3:40000~640000 adjustable /Opus:8000~256000 |
||
| PTE streams are encoded using G711A |
Disable/Enable | ||
| G711 Encoding |
Disable/Enable | ||
| RTSP streams are encoded using G711 |
Disable/enable/enable and resample to 8K |
||
| OSD | Type | Text/Image/Scroll Text/Time |
|
| Transparency | 0-255 | ||
| Zones | 4 zones optional |
||
| X coordinate |
0-1920 | ||
| Y coordinate |
0-1080 | ||
| LOGO | 4 LOGOs can be uploaded |
||
| Font Size | 8-72 | ||
| Background color |
transparent/white/black | ||
| Font color | RGB color optional |
||
| Transcoding
|
Video Transcoding |
Channels | 9 |
| Transcoded streaming protocol |
Support RTMP/ RTSP /HTTP TS/HTTP FLV/HLS/MP4/SRT/UDP Multicast/RTP Multicast |
||
| Audio Transcoding |
Encoding | AAC /AAC+/AAC++/MP3/MP2/ AC3/Opus |
|
| Encoding Bitrate |
AAC:48000~320000 adjustable/AAC+:24000~48000 adjustable / AAC++:12000~32000 adjustable /MP3:64000~320000 adjustable / MP2: 64000~320000 adjustable / AC3:40000~640000 adjustable /Opus:8000~256000 |
||
| PTE streams are encoded using G711A |
disable/enable | ||
| G711 Encoding |
disable/enable | ||
| RTSP streams are encoded using G711 |
disable/enable/enable and resample to 8K |
||
| General | Network | Dual Gigabit Network |
|
| Configuration management |
Configuration management via WEB | ||
| ONVIF | Support ONVIF search and browse video | ||
| Power Supply |
12V/DC,2A | ||
| Power | 5W | ||
| Working temperature |
-20℃+60℃ | ||
| Working humidity |
<90%, non-condensing |
||
| Weight | 372 | ||
| Size | 14.1*3.5*10.2cm | ||
