Support DiSEqC function and PLS
Key Features (Per Card/8 Input)
thru Data port,unicast/multicast-Version 2
Specifications (Per Card/8 Input)
|
Input /Output |
8 Tuner input (DVB-S/S2/S2X or/and DVB-C/T/T2/ISDB-T),F Type 8 MPTS out thru bypassing over UDP/RTP thru Data port(Version 1) 100/1000Mself-adaption,unicast/multicast |
||||
|
Mux(Version 2) |
Max number of managing PID:256(for 2 MPTS out thru multiplexing)or 512 SPTS out |
||||
|
Functions |
PID remapping (automatically/manually) |
||||
|
PID pass-through |
|||||
|
Tuner Section |
DVB-S |
Input Frequency |
950-2150MHz |
||
|
Symbol Rate |
0.5~45 Msps |
||||
|
Constellation |
QPSK |
||||
|
FEC |
1/2,2/3,3/4,5/6,7/8 |
||||
|
DVB-S2 |
Input Frequency |
950-2150MHz |
|||
|
Symbol Rate |
QPSK/8PSK/16APSK:0.5~45 Msps 32APSK:0.5~40 Msps |
||||
|
Constellation |
QPSK/8PSK/16APSK/32APSK |
||||
|
FEC |
QPSK:1/2,3/5,2/3,3/4,4/5,5/6,8/9,9/10 8PSK:3/5,2/3,3/4,5/6,8/9,9/10 16APSK:2/3,3/4,4/5,5/6,8/9,9/10 32APSK:3/4,4/5,5/6,8/9 |
||||
|
Max input bitrate per tuner |
≤170 Mbps |
||||
|
DVB-S2X |
Symbol Rate |
QPSK/8PSK/16APSK:0.5~45 Msps; 8APSK/32APSK:0.5~40 Msps |
|||
|
Constellation |
QPSK/8PSK/16APSK/8APSK/32APSK |
||||
|
FEC |
QPSK:1/2,3/5,2/3,3/4,4/5,5/6,8/9, 9/10,13/45,9/20,11/20 8PSK:3/5,2/3,3/4,5/6,8/9,9/10,23/36, 25/36,13/18 |
||||
|
|
|||||
|
|
|
|
8APSK:5/9-L,26/45-L 16APSK: 2/3,3/4,4/5,5/6,8/9, 9/10,1/2-L,8/15-L,5/9-L,26/45,3/5, 3/5-L,28/45,23/36,2/3-L,25/36,13/18, 7/9,77/90 32APSK:3/4,4/5,5/6,8/9,2/3-L,32/45, 11/15,7/9 |
||
|
Max input bitrate per tuner |
≤170 Mbps |
||||
|
Signal Strength |
-65～-25dBm |
||||
|
DVB-C |
Input Frequency |
60~890 MHz |
|||
|
Standard |
J.83A,J.83C |
J.83B |
|||
|
Constellation |
16/32/64/128/256 QAM |
64/256 QAM |
|||
|
DVB-T/T2 |
Input Frequency |
60～890 MHz |
|||
|
Bandwidth |
6/7/8 M |
||||
|
ISDB-T |
Input Frequency |
60～890 MHz |
|||
|
System |
Web management:100M NMS port |
||||
|
Language:English and Chinese |
|||||
|
Ethernet software upgrade |
|||||
|
General |
Dimensions |
482mm×328mm×44mm(WxLxH) |
|||
|
Weight |
3.5kg |
||||
|
Temperature |
0~45℃(operation),-20~80℃(storage) |
||||
|
Power supply |
AC 110V±10%,50/60Hz Or AC220V±10%,50/60Hz |
||||
|
Consumption |
≤25W(1card inside) ≤50W(2 cards inside) ≤75W(3 cards inside) |
||||
