FEATURES

1. Video Input: 8*HDMI(HDCP)
2. Bitrate mode: CBR/VBR16Kbit/s~12Mbit/s
3. Support streaming resolution settings up to 720P, 1080P HD video input
4. GOP frame rate settings supported
5. Insertable of logo and Scroll Caption; Adjustable of audio gain;
6. Capable of image parameter settings
7. Video Output: Multiple output streams per input service to support Broadcast, VOD, IPTV and OTT, Mobile/ web, Set top box applications
8. Switchable of audio output mode: Left, right and Stereo
9. Configurable of Multi-rate, Multi-resolution, Multi-protocol
10. Providing SRT/RTSP/HTTP/UDP or RTMP/HLS/M3U8 protocol
11. Support ONVIF Network Video Protocol
12. Support multiple equipments display at the same time on a computer
13. System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN7 68, LINUX
14. Web-based management
15. Full-duplex mode 1000M

1. Digital TV Broadcasting System
2. Digital TV Programs Transmission
3. Hotel TV System
4. Head-end system of Digital TV branch network
5. CATV Broadcasting system
6. Edge side of Digital TV backbone network
7. IPTV and OTT headend system
