| Item | Description |
| Network Protocol | |
| Protocol | Support SRT/HLS/RTSP/HTTP TS/HTTP FLV/RTMP/UDP |
| Video Decoding Capacity | |
| Decoding format | H.264/H.265 Baseline/Main/High Profile Level4.2 |
| Frame Rate | 1-60fps |
| Bit rate(kbit) | 32kbps-32Mbps |
| Resolution | Up to 4K@60FPS |
| Channel number | 1*4K@60FPS or 4 Channels 4K@30FPS |
| Audio Decoding Capacity | |
| Decoding format | G711A/G711U/AAC+/AAC++/MP2/MP3 |
| Audio mode | Mono/Left, Right/Stereo |
| Sample rate(Hz) | 8KHz/11.25KHz /22.5KHz /44.1KHz /48KHz |
| Channel number | 1*4K@60FPS or 4 Channels 4K@30FPS |
| Video Output | |
| HDMI | 3840x2160P60/3840x2160P50/3840x2160P30/3840x2160P25/3840x2160P24/2560x1600P60/2560x1440P60/2560x1440P30/1920x2160P30/1920x1200P60/1600x1200P60/1920x1080P60/1920x1080i60/1920x1080P50/1920x1080i50/1920x1080P30/1920x1080P25/1920x1080P24/1366x768P60/1280x720P60/1280x720P50/720x576P60/720x480P60 |
| Color | Brightness, Contrast, Hue, Saturation can be adjustable |
| Audio Output | |
| HDMI audio embedded | 48KHz stereo output |
| 3.5mm | Stereo output (Left & Right) |
| Audio control | Enable/Disable |
| The Working Environment | |
| Warranty | 5 years Warranty |
| Network | 1000M |
| Management | Web management |
| Power | 12V/DC, 2A |
