| Input | 4/8/12/16/20/24 HD MI (support HDCP) | |
| 2 ASI input | ||
| IP input over UDP/RTP/RTSP protocol, 1000M | ||
| Output | 2 ASI output | |
| IP output: 4/8/12/16/20/24 SPTS and 4 MPTS output, IP output over UDP and SRT/HLS/HTTP/RTMP/UDP/RTP/RTSP protocol, support multicast (for UDP only) and unicast |
||
| Video | Encoding | MPEG-4 AVC/H.264 |
| Resolution |
Input: 1920×1080_60P, 1920×1080_60i, 1920×1080_50P, 1920×1080_50i, 1280×720_60P, 1280×720_50P, 720×576_50i,720×480_60i, |
|
| Output: 1920×1080_60P, 1920×1080_50P, 1280×720_60P, 1280×720_50P, 720×576_50P, 720×480_60P 1920×1080_30P,1920×1080_25P, 1280×720_30P,1280×720_25P, 720x576_25P,720x480_30P |
||
| Bit-rate | 1Mbps~15Mbps（each channel) | |
| Rate Control | CBR | |
| Audio | Encoding | MPEG-1 Layer 2, LC-AAC, HE-AAC v1&v2, AC3 |
| Sampling rate | 48Khz | |
| Bit-rate | 64kbps,128Kbps,192kbps,224kbps,256kbps,320kbps,384kbps | |
| Resolution | 24-bit | |
| Audio Gain | 0-255 Adjustable | |
| Multiplexing | Maximum PID Remapping | 180 output PIDS per channel |
| Function | PID remapping ( automatically or manually) | |
| Accurate PCR adjusting | ||
| System function | Network management(WEB) | |
| Chinese and English language | ||
| Ethernet software upgrade | ||
| Miscellaneous | Dimension (W×L×H) |
482mm×480mm×45mm |
| Environment | 0~45℃(work)；-20~80℃(storage) | |
| Power requirements | AC100~240V，50/60Hz | |
