Features:
1. Switching power supply for installation flexibility and precise voltage regulation
2. Two cooling fans for long life performance
3. 42dBmV chassis output level, no need extra combiner
4. SAW (surface acoustic wave) filtering on IF for superior in band C/N
5. Front panel access controls enable easy setup
Specification:
Chasssis Part
Frequency range : 47~860MHz
Output level :≧42dBmV
C/N in-band :60dB
C/N out-band :62dB
Video input connector : RCA (Yellow)
Audio input connector :RCA (White)
RF output connector :75Ω F-Female
Voltage input :DC 5V for mini modulator; AC 240V input chassis
Modulator Part
Output Frequency : 47-860MHz
Output Level: 95dBµV(Adj.)
A/V Ratio : -11 to -18dB(Adj.)
Frequency Stability: ±5KHz
Video : 75Ω F-female
Input Level: 0.6-1.5Vp-p(87.5% Modulation)
Video C/N : 50dB
Hum/Noise: -50dB
Modulation Range : 0~90%
Audio: 75ΩF-female
Input Level : 1Vp-p(25KHz Dev.)
Distortion:1%
