| HDMI Encoding Section | ||
| Video | Encoding | HEVC/ H.265 , MPEG 4 AVC/H.264 |
| Interface | 24 HDMI input | |
| Resolution | 1920*1080_60P, 1920*1080_50P; 1920*1080_59.94P, 1280*720_60p, 1280*720_59.94 1280*720_50P |
|
| Chroma | 4:2:0 | |
| Bitrate | 1Mbps~15Mbps | |
| Rate Control | CBR/VBR | |
| GOP Structure | IP | |
| Audio | Encoding Format | MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2; AC3 Pass-through |
| Sample rate | 32KHz,44.1KHz,48KHz | |
| Bit-rate | 48~384Kbps | |
| Stream output | IP out over UDP (Unicast/Multicast),SRT, RTP,RTSP, RTMP, HTTP, HLS (RJ45, 1000M ) (8 HDMI inputs with 8 SPTS for each encoder board) | |
| System function | Network management(WEB) | |
| Chinese and English language | ||
| Ethernet software upgrade | ||
| Miscellaneous | Dimension (W×L×H) | 482mm×328mm×44mm |
| Environment | 0~45℃(work)；-20~80℃（Storage） | |
| Power requirements | AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz | |
