| Technical Parameters | OT1300-3*** | OT1300-5*** | |
| Output optical power | 2~30mW | 3~10dBm | |
| Wavelength | 1310nm±20 | 1550nm±15 | |
| Laser type | DFB laser | ||
| Optical modulation | Direct light intensity modulation | ||
| Optical connector form | FC/APC&SC/APC（customize） | ||
| Frequency Range | 47~862MHz（customize 1000MHz） | ||
| RF input level | 75~90dBuV（Recommended best value 80dBuV） | ||
| In-band flatness | ±1dB | ||
| AGC accuracy | 0.5dB | ||
| MGC adjustment range | 0~15dB | ||
| RF input impedance | 75Ω | ||
| Input reflection loss | ≥16（40-550）；≥14（550-860） | ||
| C/CTB | ≥51 | ≥51 | |
| C/CSO | ≥65 | ≥70 | |
| Carrier to noise ratio (C/N) | ≥60 | ≥70 | |
| Supply voltage | AC110/220（90~265v）or DC48v（38~58v） | ||
| Total power consumption | ＜12W | ||
| Operating temperature | -5℃~+45℃ | ||
| Relative humidity | 95% max, no condensation | ||
| Storage temperature | -30℃~+70℃ | ||
| Product net size | 482(W)*356(D)*44(H) | ||
| Single product packaging size | 590(W)*505(D)*115(H) | ||
